Product description
While for some the thrill of a DIY is great, others just want a machine which plugs in and works. The FabCore Plus has all the great features of the FabKit but ready to go!
Available as standard with the Fab75w tube, active chiller and 1.1kw extractor, the FabCore Plus is a power house of cutting while remaining as compact as the FabKit.
Product Features
Included as standard
FabCore Plus | 1 |
FabCool Active | 1 |
FabAir Plus | 1 |
1.1Kw extractor | 1 |
Extraction hose | 2.5m smoothbore |
Water hose | 3m Silicon hose |
Starter box | 1 |
Technical Data
Model | FabCore Plus Mk1 |
Manufacturer | FabCreator V.O.F. |
Country of Origin | The Netherlands |
Electrical specifications | 220-240V, Max 5 amp |
Laser Power | 75w Nominal (90w Peak) |
Lens* | ZnSe II-VI infrared 58.1mm Focal length, Approx. 200μm spot size. |
Recommended Raster speed* | 500mm/s |
recommended Vector speed* | 30mm/s |
Accuracy* | +-100μm |
Dpi | 1000dpi* |
Machine Size (WxDxH) | 1266x816x503 mm |
Packaging Size (WxDxH) | 130x110x100 cm |
Machine weight | 92kg |
Laser work Area | 800x500x130mm |
Focus | Quick & easy manual focus |
Work surface | Steel grid |
Connectivity | USB Connection, USB Stick |
Software | LightBurn DSP, |
File Formats | SVG, DXF, AI, PDF, BMP, PNG, JEPG |
Laser Safety | Class 1 laser product (EN 60825-1:2014) Suited for freely accessible locations such as schools and libraries |
Laser Classification | Class 1 laser product (EN 60825-1:2014) |
Safety system | Performance level D Category level 3 (EN13849-1:2015) |
European Directives | MD, EMC, RoHS, WEEE, (see Safety for more info) |
*Explanations
