FabCool Active Chiller
€750.00
Available to Order
Product Details
Product description
The FabCool Active chiller ensures 24/7 operation even in warmer climates.
With an active refrigeration loop the FabCool Active chiller is constantly maintaining a stable temperature for your laser tube. This stability will extend the expected life span of your laser tube. When you upgrade to the Active chiller you will receive an additional 6 months warranty with your laser tube!
When you buy the FabCool Active chiller with your machine you receive a large discount. Check under your chosen machines options in the store!
Technical Data
| Model | FabCool Active |
| Manufacturer | Teyu chiller S&A |
| Voltage | AC 1P 220-240V |
| Frequency | 50/60 Hz |
| Current | 0.8~3.5A |
| Machine power | 0.51/0.53kW |
| Compressor power | 0.37/0.39kW |
| 0.5/0.53HP | |
| Nominal cooling capacity | 3037/3686Btu/h |
| 0.89/1.08kW | |
| 765/928Kcal/h | |
| Refrigerant charge | 280g |
| Pump power | 0.1kW |
| Max. lift | 25M |
| Max. flow | 16L/min |
| N.W. | 25Kgs |
| G.W. | 28Kgs |
| Refrigerant | R-134a |
| Precision | ±0.3℃ |
| Reducer | Capillary |
| Tank capacity | 6L |
| Inlet and outlet | OD 10mm barbed connector |
| Dimension | 58 X 29 X 47cm (L X W X H) |
| Package dimension | 65 X 39 X 51cm (L X W X H) |
| Approvals | CE, REACH, RoHS |
| Warranty | 2 Years |
Product Features
- Cooling Capacity: 800W
- Pre-configured at 17°C
- Active cooling
- Temperature stability: ±0.3°C
- Temperature control range: 5°C ~35°C
- Refrigerant: R-134a
- Compact, portable design and quiet operation
- High efficiency compressor
- Top mounted water fill port
- Integrated alarm functions with Laser cutter
- Low maintenance and high reliability
- 50Hz/60Hz dual-frequency compatible available
- Heater
